STANDARDS

IEC 61000-4-2, IEC 61340-3-1, IEC 61340-3-2, ISO 10605, MIL-STD-461 / CS118, MIL-STD-331, ANSI C63.16, JESD22-A114-B, JESD22-A115-A, SAE J551-15

IMPULSES / CIRCUITS

ESD

FEATURES

Load and save predefined or customized tests

Programmable level- and polarity ramp

Low weight standalone generator. Battery powered

Wide range of modular discharge modules

Highest Test Levels

BENEFITS

Get Testing Faster – Minimum learning time, Easy to follow interface, No big case unit, full mobility

Save Time – Reduce setup time with automated test routines, real parameter change, ideal development tool

Upgrade on Site – Optimize usage, calibrated extensions exchanged on site

Keep Testing – 8 hours time between battery charges

Only Need One Tester – Expandable to many applications. Cost effective solution

Related Products and Accessories

ESD TEST ACCESSORIES

EARTH CABLE
Connection cable 2m with 2x 470kOhm resistors

ESD-HCP-AUTO
Indirect ESD Field-Coupling-Plane

ESD-STAND Ed2
Stand for, ESD2000, ESD3000, ESD3000DM-EXT

ESD-TARGET2
2 Ohm Target with SMA connector. Calibrated target attenuator cable chain up to 10kV

ESD-TARGET2 DN
2 Ohm ESD Target with SMA connector & target attenuator cable chain for up to 30kV

ESD-VCP50
ESD-VCP50 to ESD3000 and ESD2000 generators:

ESD-VERI-V
Charging voltage measurement divider 20GOhm

ESD3000 CNH12
Magnetic field loop for ESD3000 test system

ESD3000 SAFETY-S
SAFETY-S TO ESD3000 SYSTEM FOR TESTING EXPLOSIVE DEVICES

ESD3000-OPTOLINK
Optical fibre 10 m, connects ESD3000 to computer/TEMA.

ESD3000DM-EXT
Cable extension to separate the control unit and discharge module.

TC-MIG24ED
Test cabinet to test explosive devices.With interlock safety switch and warning lamps

MODULES TO ESD3000
ESD3000DM1
Electrostatic Discharge Module 150pF, 330 Ohm for AD up to 16kV, CD up to 10kV

ESD3000DM16A-C63H
Discharge module according to ANSI C63.16.

ESD3000DM16C-C63H

ESD3000DM2
Discharge module according to ISO TR10605. 330pF, 2000 Ohm.

ESD3000DM32A-UL991

ESD3000DM4
Discharge module according to MIL-STD- 883 and GR-78-CORE

ESD3000DM6
Discharge Module according to IEC 61340-3-1. (Human Body Model)

ESD3000DM7
Discharge Module according to IEC 61340-3-2 (Machine Model). 200pF, 0 Ohm

ESD3000DN1
Discharge Network up to 30kV according ISO TR 10605. 150pF, 330 Ohm

ESD3000DN2
Discharge Network 330pF, 2000 Ohm. AD and CD 1kV up to 30kV

ESD3000DN3
Discharge Network 150pF, 2000 Ohm. AD and CD 1kV up to 30kV

ESD3000DN32-CAR1
Discharge network for automotive testing 150pF, 500 Ohm up to 30kV

ESD3000DN32-CAR5
Discharge network for automotive testing. 330pF, 0 Ohm. AD and CD up to 30kV

ESD3000DN32-IND1

ESD3000DN32-MIL2

ESD3000DN32-MIL3
Discharge network for ESD3000 up to 30kV

ESD3000DN4
Discharge network for explosive device testing 500pF, 5000 Ohm. AD and CD 1kV up to 30kV

ESD3000DN5
Discharge network for military testing 500pF, 500 Ohm. AD and CD 2kV up to 30kV

ESD3000DN6
Discharge Network 330pF, 330Ohm up to 30kV Contact & Air Discharge

ESD3000RM32
Relay module with high voltage and polarity switch
